Specifications:

• 16 inputs. 48V Phantom Power.
• 3 Band Channel EQ. (High, Mid & Low).
• Frequency response 25Hz – 20 kHz.
• 60mm Long Taper Fader.
• Gain: -10db to – 60db.
• S/N Ratio 89db Distortion 0.01%.
• 3 Aux send (Pre – fader & Post fader)
• Built-in DSP digital 99 Effects.
• 7 Band Stereo GraphicEquiliser.
• Power Supply: 220V AC 50Hz
• Dimension: 625(W) x 390(D) x 90(H)mm.
• Weight: 6.600 kg. (Approx.)
